Description

GENERAL
- Capacity: 650VA
- Dimension (mm): 279 x 101 x 142 (D x W x H)
- Weight (kg): 4.2
*INPUT
- Nominal Voltage: 230VAC
- Voltage Range: 140 - 300 VAC ± 5%
- Nominal Frequency: 50 or 60Hz (Auto sensing)
*OUTPUT
- Voltage Regulation: ± 10%
- Frequency: 50 or 60Hz ± 1Hz
- Transfer Time (typical): 2 - 6ms
- Waveform: Simulated Sinewave
*BATTERY
- Number of Battery: 12 V/8.2 Ah x 1
- Recharge Time (typical): 2-4 hours recover to 90% capacity
*ALARM & INDICATORS
- LED Display: AC Mode - Green Lighting, Battery Mode - Yellow Flashing every 10 seconds, Overload - Red Flashing every second, Fault - Red Lighting
- Sounding: Battery Mode - Sounding every 10 seconds, Low Battery - Sounding every second, Overload - Sounding every 0.5 second, Battery Replacement Alarm - Sounding every 2 seconds, Fault - Continuously sounding

- Warranty: 2 Years
- Noted: 12M Battery warranty only
